GPS Compass

DESCRIPTION

This new sensor based on satellite technology overcomes boat magnetic problems and a compass calibration often difficult.

This is the new 10 Hz. satellite Compass from nke. It delivers true heading accurately anywhere in the world as well as GPS position and course over ground.

CHARACTERISTICS

Receiver specifications:

  • Communication: Serial port: 1 NMEA 0183 serial port
  • Frequency : 10 Hz
  • Heading resolution : 0.1°/1m
  • Data: GPS Heading, COG, SOG, UTC
  • Environment:
    • Temperature: – 40°C to +85°C
    • Waterproof protection : IP66
    • Dimensions: 160 x 90 x 50 mm
  • Power supply:
    • Receiver power supply: 9 to 32 VDC
    • Receiver + antenna consumption: 315mA

Antennas specifications :

  • Weight : 0.300 gr
  • Dimensions : 126 x 81 mm
  • Power supply : 3-15 V (operating)
  • Ref. 90-60-520

FUNCTIONS

The GPS Compass does not require any calibration, being independent from all magnetic influences on board. This is the best heading data alternative in regions where magnetic compasses are not reliable (south seas)



It is directly connected to the bus instead in place of a Regatta Compass or GPS.

GPS Compass comes with two antennas installed independently to each-other. The more distance between the antennas the better the data produced.
