Analog Monitor Interface

DESCRIPTION

Customize Your setup : 1 sensor  = 1 channel on the bus.

Create and publish on the Bus Topline Bus data from any third sensor type analog voltage (ex mast angle sensor, keel angle, tank gauges …). Wide range of sensors can be used : keel or mast angle, inductive or analog sensors.

The analog Monitor enables to create one channel per interface with a custom title. Then these channels can be displayed on multifunctions.

CHARACTERISTICS

  • Dimensions : 110 X 56.4 X 26 mm
  • Voltage : 9 to 32 Volt DC
  • Consumption :< 20 mA
  • 1 analog enter 0 to 3.3 V or 0 to 10 V
  • Ref. 90-60-539
